Nautiz X21

Handheld Nautiz X21 Waste Mangement Gold

Spezifikationen

Dimensions: 167 mm x 75.5 mm x 17 mm
Weight: 295g
Processor: Qualcomm Snapdragon™ 6490 Processor, 64bits, Octa-Core up to 2.7 GHz AI Engine, 6th generation
Graphics: Adreno 643 GPU
RAM: 6 GB
Storage: 64 GB
Operating System: Android 14 (GMS) Android Enterprise Recommended
Display: 6.3” Color LCD 1080 X 2340 (FHD+) High Resolution Display High sunlight visibility- LCD backlight up to 500nits. Gorilla Glass with Multi-Touch Capacitive Touch Panel, support stylus, glove, wet-finger Compatibility
Buttons: Side Programmable key, Volume up/down key, Left/right scan key, Power key

Battery

5100mAh Li-ion battery Hot-swappable for up to 1 minute

Ports

USB 3.1 type C, supports fast charging, OTG, Display Port. Ethernet via dongle or cradle Nano SIM Slot x 2 Micro SD x 1, up to 1TB Bottom pogo pins for charging in cradles Rear pogo pins for expansions

Communication

Cellular (WWAN)
5G: n1/n2/n3/n5/n28/n41/n71/n77/n78/n79
(4×4 MIMO)
4G LTE(FDD) – Bands 1, 2, 3, 4, 5, 7, 8, 12, 17, 20, 28
(TDD) – Bands 38, 39, 40, 41, 71
3G UMTS/HSPA+ – Bands 1, 2, 5, 8
2G GSM/GPRS/EDGE (850/900/1800/1900 MHz)
*Supports Dual Sim Dual 5G
*Supports 4G LTE Advanced , Up to CAT12 LTE downlink/uplink

Wireless LAN
Wi-Fi 6E+DBS, 2.4GHz & 5GHz & 6GHz
IEEE 802.11a/b/g/n, ac/ax, e/k/r/v/u PMKID (2×2 MU-MIMO)
Security WPA3, WPA2

PAN
BT 5.2, BLE 5, Class 1.5

NFC
13.56 MHz
ISO14443A/B, ISO15693, Mifare, Felica(ISO/IEC18092)

Audio
Speaker 1.5W. 100 dB at 10cm
Dual-Microphone support noise cancellation

Positioning

GPS, Galileo, GLONASS, Beidou, QZSS, SBAS Supports L1+L5, a-GPS, XTRA

Cameras

Rear 16 megapixel with auto-focus and flash Front 5 megapixel

Sensors

Gyroscope, G-sensor, E-compass, Light & Proximity Sensor

Data collection

Built-in 2D imager N6703SR/N6803FR (Optional)

Environment

Operating
-20°C to 55°C (-4°F to 131°F)
Charging: 0°C to 45°C (32°F to 113°F)

Storage
-40°C to 70°C (-40°F to 158°F), without battery

Drop / Shock
MIL-STD-810H:2019 Method 516.8/Procedure IV, 1.2m (4ft)
Drop tested from 1.8m/1.5m with bumpers

Vibration
MIL-STD-810H:2019, Method 514.8, Procedure I
Tumble tested 300 cycles (0.5m/1.6 ft.)

Sand / Dust
IP65 & IP68 per IEC 60529

Water
IP65 & IP68 per IEC 60529

Humidity
MIL-STD-810H:2019, Method 507.6, Procedure II – Aggravated Cycle
95%RH
