Nautiz X6

Tekniska specifikationer

Dimensions

194 mm x 92 mm x 15 mm

Weight

380 g

Processor

Qualcomm® Snapdragon 626 MSM8953 Pro, 8 cores 2.2 GHz

Graphics

Adreno 506

RAM

4 GB

Storage

64 GB

Operating System

Android 11 (GMS) Android Enterprise Recommended

Display

6” capacitive multi-touch (10 points)

1080×1920 pixels

Sunlight readable

Glove/rain mode

Corning® Gorilla® Glass

Buttons

Front F1, F2, F3, power Side FN, volume up/down

Battery

3.8V 8.000 mAh (30.4 Wh)

field replaceable

Ports

Type-C, OTG Qualcomm quick charge 3.0

GNSS antenna connector

Back connector for expandability

1x micro SDXC (256 GB)

2x nano SIM

Communication

Cellular (WWAN)
2G (850,900,1800,1900)
3G (1,2,5,8)
4G/LTE (1,2,3,4,5,7,8,12,13,17,20,25,26,28,38,39,40,41)

Wireless LAN
2.4 GHz + 5 GHz
802.11a/b/g/n/ac

PAN
BT V4.2 LE

NFC
13.56 MHz
ISO 14443A/B, ISO 15693

Audio
Headphone support via Type-C
Front-facing speaker
Microphone

Positioning

GPS/AGPS/GLONASS/Galileo/BeiDou

Cameras

Rear: 13 megapixel with auto-focus and flash

Front: 5 megapixel

Sensors

Gyroscope Compass Accelerometer Pressure Proximity Ambient light

Data collection

Environment

Operating
-20°C to 55°C (-4°F to 131°F)
MIL-STD-810G, Method 501.5/502.5 Procedure II

Storage
-40°C to 70°C (-40°F to 158°F)
MIL-STD-810G, Method 501.5/502.5 Procedure I

Drop / Shock
6 drops from 1.5m, concrete surface
IEC 68-2-32:1990

Vibration
MIL-STD-810H:2019 Method 514.8/Procedure I

Mechanical
MIL-STD-810H:2019 Method 516.8/Procedure I

Sand / Dust
IP67, IEC 60529

Water
IP67, IEC 60529

Humidity
0% ～ 95% (non-condensing)
MIL-STD-810G, Method 507.5 Procedure II

Altitude
4572 m (15 000 ft)
MIL-STD-810G, Method 500.5 Procedures I & II

EMC/EMI
MIL-STD-461F, CE101, CE102, CS101, CS114, CS115, CS116, RE101, RE102, RS101, RS103
