Algiz RT8
Tekniska specifikationer
- Dimensions
- 249 mm x 145 mm x 14.5 mm
- Weight
- 635 g
- Processor
Qualcomm® Snapdragon 625 MSM8953, 8 cores 2.0 GHz
- Graphics
- Adreno 506
- RAM
- 4 GB
- Storage
- 64 GB
- Operating System
- Android 11 (GMS)
- Display
8” capacitive multi-touch (10 points)
1.920 x 1.200 pixels
Sunlight readable
Glove/rain mode
Corning® Gorilla® Glass
- Buttons
Front:
Power, F1, F2, F3, Volume up/down
- Battery
3.8V, 8.200 mAh (31.16 Wh)
field replaceable
- Ports
Type-C, Fast chargingQualcomm quick charge 3.0, OTG
GNSS antenna connector
Docking connector supporting HDMI, Ethernet, USB
Back connector for expandability
3.5mm headphone jack
1x micro SDXC (128 GB)
1x Nano-SIM
- Communication
Cellular (WWAN):
2G (850,900,1800,1900)
3G (1,2,5,8)
4G/LTE (1,2,3,4,5,7,8,12,13,17,20,25,28,38,39,40,41)
Wireless LAN:
2.4GHz/5GHz, 802.11a/b/g/n/ac
PAN:
BT V4.1
Audio:
Rear-facing speaker, microphone
- Positioning
Dedicated u-blox GNSS receiver
GPS/GLONASS/Galileo/BeiDou
- Cameras
Rear:
13 megapixel with auto-focus and flash
Front:
5 megapixel
- Sensors
Gyroscope, Compass, Accelerometer, Pressure, Proximity, Ambient light
- Data collection
NFC, 13.65 MHz
ISO 15693, ISO 14443 A/B
- Environment
Operating:
-20°C to 60°C, MIL-STD-810G, Method 501.5/502.5 Procedure II
Storage:
-40°C to 70°C, MIL-STD-810G, Method 501.5/502.5 Procedure I
Drop/shock:
26 drops from 1.2 m, MIL-STD-810G, Method 516.6 Procedures IV
Vibration:
MIL-STD-810G, Method 514.6 Procedure I
Sand and Dust:
IP67, IEC 60529
Water:
IP67, IEC 60529
Humidity:
0% ～ 95% (non-condensing), MIL-STD-810G, Method 507.5 Procedure II
Altitude:
4572 m, MIL-STD-810G, Method 500.5 Procedures I & II
EMC/EMI:
MIL-STD-461F: CE101, CE102, CS101, CS114, CS115, CS116, RE101, RE102, RS101, RS103
